SF-280S Fingerless adsorption single facer
Use and Characteristics
1. Design speed: 100m/min.
2. Effective width: 1400mm- 1800mm.
3. Corrugated roller: φ 280mm.
4. The driving reducer adopts oil penetration lubrication, reducing noise, universal joint drive and isolating power source.
5. Upper roller, pressure roller and rubber roller lift, all with pneumatic control.
6. The guide paper adopts vacuum adsorption, with air volume adjustment device, to maintain the stability of corrugated type in
high speed.
7. The roller and pressure roller bearings are lubricated with high temperature resistance grease.
8. The gelatinize part adopts automatic circulation for glue.
9. The upper and lower corrugated roller adopts 48CrMo high quality chromium aluminum alloy steel, after heat treatment, the
hardness is grinding on the surface of hrc58o-60o.
10. The surface of the rubber roller has been treated with the mesh cut and chrome plating.
11. Manual or electric separation device.
12. The machine can operate independently or without independent operation, and the main power converter control (optional).
∗Adopt hood suction structure,matched high pressure powerful fan. Gas supply and electrical control cabinet to focus on the same operation, the operating side full cover closed.
∗High quality resin sand casting,wall thickness 200mm.Adopt independent gear box, Universal joint transmission structure.
∗Glue roller unit structure with the overall relocation,Maintenance can sway the machine at the overall maintenance,improve the working efficiency.
∗The humidity control apparatus equipped with a spray, so flute type to maintain good stability of deformation, avoid dry.
∗Glue department using integrated slide structure,Glue roller surface after grinding engraved with 25 lines and pit-style textured hard chrome plating.
∗Active force variable frequency motor drive, energy efficient, low failure rate.
∗Amount of glue size with electric adjustment, touch screen display and operation of the encoder transmission coating gap, high accuracy.
∗Power and operating parts with a safety net to ensure the safety of personnel in the operation of machinery.
