Duplex gluing machine
Equipment Standards
1. Design speed of 250m/min, with a diameter of 320mm
2. The rotation of each layer of pasting wheel is controlled by the inverter motor, which is controlled by the frequency converter to ensure the synchronization of each layer of paste speed and can be operated separately.
3.Since the rotation of each layer of the paste wheel is controlled by the variable frequency motor, it can still be controlled by the frequency converter with the same speed on the same line as the converter.
4. The control of the amount of paste and the amount of control can be separated and automatic.
5. According to the speed of the moving motor to achieve the required amount of control.
6. According to the variation of speed automatically when completed by coder and PLC automatic control and man-machine interface display values, to ensure that the corrugated machine at high and low speed see paste on the amount needed to ensure the stability of the pit of paper quality.
7. When the roller stops, the roller will lift automatically, and the roller will be automatically idled.
8. Optional roller compression or elastic contact pressure.
Use and Characteristics
Effective width: 1400mm-2500mm
. Corrugated roller:φ380mm
.Fingerless vacuum suction type single facer, the upper and lower corrugated roller made of 52 CrMo alloy steel,with harted treatment,the hardness is above HRC58o-60oThe surface is well treated by grind and plated chrome.
.With preheater for liner paper and steam spray device for medium paper.
.Upper and lower corrugated roller are unit assemblage, the whole corrugated rollers group can be move and quick replacement, to change flute type quickly.
.Glue section are unit assemblage, whole section can be moved by track,save maintenance time.
.Adjustment for corrugated roller,pressure roller,and glue roller by pneumatic system.
.Frequency conversion motor as main drive , independent gear box connect with three gimbal axis, Inverter to make stepless speed regulation for save power, and to keep one communication connector for production management.
.Oil immersed type lubricating to reduce noise keep running stable, prolong the use life of gear.
.Adopt Glue width motorized dividing to match the paper width. Idle running motor for glue applicator roll to avoid glue dry.Adjustment for gap between glue roller and doctor roller by electric or manual are optional, Digital read out for the gap between glue roll and doctor roll is optional.
.Bearing for corrugated rollers,and pressure roler adopt high-temperature lubricate grease to keep running smoothly and durably
Product parameter
|
Model number |
Working Speed |
Type of corrugation |
Way of heating |
|
1600 |
0-35 |
A C B E |
Electric . steam , oil |
|
1800 |
0-35 |
A C B |
Electric . steam , oil |
|
2000 |
0-35 |
A C B |
Electric . steam , oi |
